Description
Description: UPS ONLINE LCD 750VA 675W
Tripp Lite UPS Smart Online 750VA 675W Rackmount 100V-120V LCD USB DB9 2URM RT – UPS – AC 100/110/115/120/127 V – 675 Watt – 750 VA – RS-232, USB – output connectors: 6 – 2U
Tripp Lite Smart Online UPS systems offer high performance power protection ideal for critical server and network equipment in datacenters, computer rooms and network closets. Online, double-conversion Uninterruptible Power Supply (UPS) maintains perfectly regulated output power by continuously converting raw AC input to DC, then re-converting output back to AC. Fully regulated sine wave AC output with +/-2% voltage regulation powers network equipment continuously, even during severe brownouts and overvoltages, all without depleting UPS battery reserves. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Highly efficient operation in optional economy mode saves BTU heat output and energy costs. Built-in DB9 port offers both enhanced RS-232 data and basic contact closure monitoring ability. LED display reports UPS operating mode, line power availability, battery mode operation, inverter operation, ECO mode status and output power availability. LED/LCD display panel easily rotates for viewing in rackmount or tower configurations.
Key Selling Points
Two switched outlets support remote reboot or programmable load shedding options
Supports 2% output voltage regulation and zero transfer time in double conversion mode
Economy mode option offers enhanced efficiency, reduced power consumption and lower BTU emissions
LCD interface reports operating mode plus 9 selectable screens of UPS data
LCD interface also supports 16 screens of UPS configuration and setup options
Single line TEL/network surge suppression
Electronic bypass maintains utility output during a variety of UPS fault conditions
Frequency regulation/conversion mode offers generator-compatible frequency correction or conversion of frequency from 50 to 60 Hz or 60 to 50 Hz
Built-in USB, RS-232, contact-closure and optional SNMPWEBCARD accessory monitoring options
