Sale!

Tripp Lite 30kVA 30kW Smart Online 3-Phase UPS 208/120V 220/127V Tower DB95.50 Minute Full Load15.70 Minute Half Load30 kVA / 30 kWSN… SUT30K

Original price was: $27,288.00.Current price is: $25,923.60.

Tripp Lite 30kVA 30kW Smart Online 3-Phase UPS 208/120V 220/127V Tower DB9
On-line double-conversion topology, VFI operation.
1.0 unity power factor supports 30kVA/30kW capacity.
Up to 98% economy-mode efficiency option saves energy.
Internal batteries included with external battery pack options.
Parallel up to 4 units for increased capacity or N+1.

SKU: SUT30K Categories: , , Brand: Tripp Lite

Description

Tripp Lite 30kVA 30kW Smart Online 3-Phase UPS 208/120V 220/127V Tower DB9
The SUT30K SmartOnline® SUT Series 3-Phase 208/120V 220/127V 30kVA 30kW On-Line Double-Conversion UPS provides complete protection against power interruptions and fluctuations that can contribute to equipment failures and data loss. It’s recommended for critical data center, telecommunications, computer network, light industrial and financial applications.

The Voltage and Frequency Independent (VFI) design allows continuous operation at either 50 or 60 Hz. Zero transfer time from online to battery mode ensures no disruption to attached equipment loads. Offering an efficiency of 94% during normal operation and 98% in economy mode, the SUT30K reduces energy losses for cost-saving operation. Automatic bypass keeps connected equipment powered, even during overloads and many potential UPS fault conditions.

IGBT inverter technology produces output power with less than 2% total harmonic distortion (THDi) to keep connected equipment functioning at its peak. A 3:1 crest factor safely supports a variety of loads, even those with wildly fluctuating power demands.

Managing the SUT30K is simplified through the multi-language LCD interface, which displays critical operating conditions and diagnostic data, such as battery and load status. Four LEDs indicate AC, bypass, battery and fault modes. A built-in card slot supports optional remote management cards, such as WEBCARDLX, for comprehensive monitoring and control over a network.

Additional information

Weight 1204 lbs
Dimensions 31.50 × 20.50 × 53.15 in
Application/Usage Datacenter, Network, Telecommunication
Package Contents SmartOnline SUT30K 30kVA Tower UPS, RS-232 (DB9) Cable, Owner's Manual,
Product Type Dual Conversion Online UPS
Input Voltage 120 V AC, 230 V AC
Manufacturer Part Number SUT30K
Manufacturer Website Address http://www.tripplite.com
Limited Warranty 1 Year
Output Voltage 120 V AC, 230 V AC
Form Factor Tower
Load Capacity 30 kVA
Manufacturer Tripp Lite by Eaton
Product Model SUT30K
Product Name SmartOnline SUT30K 30kVA Tower UPS
Network Management SNMP Manageable
Product Line SmartOnline
Waveform Type Pure Sine Wave
Product Series SUT
Brand Name Tripp Lite
Plug/Connector Type Hardwired
Country of Origin China
Phase Three Phase
Receptacle Type Hardwired
Environmentally Friendly Yes
Environmental Certification RoHS
Backup/Run Time (Half Load) 15.70 Minute
Backup/Run Time (Full Load) 5.50 Minute
GTIN 0037332186706
UPC 037332186706
EAN 0037332186706
UNSPSC 39121011
