StarTech.com 1 Port Low Profile PCI Express Serial Card – 16550
One high speed RS232 serial port with data transfer rate up to 460.8 Kbps.
Ships with half-height/low profile mounting bracket, includes standard bracket.
Selectable power output on pin 9 for the serial port.
Native single-chip, single lane PCI Express.
Single chip design optimizes speed and reliability.
Compliant with PCI Express base specifications revision 1.1a.
Automated out-of-band flow control using CTS/RTS and DSR/DTR.
Automated in-band software flow control using programmable Xon/Xoff in both directions.
256 Byte FIFO.
One high speed RS232 serial port with data transfer rate up to 460.8 Kbps.
Ships with half-height/low profile mounting bracket, includes standard bracket.
Selectable power output on pin 9 for the serial port.
Native single-chip, single lane PCI Express.
Single chip design optimizes speed and reliability.
Compliant with PCI Express base specifications revision 1.1a.
Automated out-of-band flow control using CTS/RTS and DSR/DTR.
Automated in-band software flow control using programmable Xon/Xoff in both directions.
256 Byte FIFO.

SKU: PEX1S553LP Categories: , , Brand: Startech

Description

StarTech.com 1 Port Low Profile PCI Express Serial Card – 16550

The PEX1S553LP PCI Express Serial Card turns a PCI Express slot into an RS232 (DB9) serial connection.

The card is constructed using a native single chip design that lets you harness the full capability offered by PCI Express (PCIe), while reducing the load applied to the CPU by as much as 48% over conventional bridge chip serial cards.

The PCI Express RS232 Serial Adapter Card is compatible with a broad range of operating systems, including Windows® and Linux Kernel 2.6.11 to 4.11.x, and ships with a low profile/half-height bracket installed, but includes an optional full profile bracket that lets you add a serial port to virtually any computer (regardless of the case form factor).

This product is a replacement for our PEX1S552LP card.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

Additional information

Weight 0.1 lbs
Dimensions 175.00 × 3.10 × 0.80 in
