Cyber Power OL6KRTMBTF Smart App Online UPS Systems6000VA/6000W, 200240 VAC, Hardwire, 8U, Rack / Tower, Sine Wave, 13 Outlets, LCD, Pow… OL6KRTMBTF

Cyber Power OL6KRTMBTF Smart App Online UPS Systems6000VA/6000W, 200240 VAC, Hardwire, 8U, Rack / Tower, Sine Wave, 13 Outlets, LCD, Pow… OL6KRTMBTF

$5,159.00

CyberPower OL6KRTMBTF Smart App Online UPS Systems
Offers power supply with zero transfer time taken to the battery and proves ideal for voltage sensitive equipments.
Keep your sensitive devices powered with a backup of up to 4.40 minute at full load.
Capacity: 6000 VA / 6000 W.
Power Factor (PF): 1.0.
Topology: Double-Conversion.
Waveform: Sine Wave.
Output: 120 VAC; 200, 208, 220, 230, 240 VAC User Configurable ±2%.
Plug type & cord: Hardwire.
Outlet types: 6 x NEMA 5-20R, 2 × NEMA L6-20R, 4 x NEMA L6-30R, 1 x Hardwire Terminal Block.
Maintenance Bypass Switch: Yes.
Communication ports: USB, Serial, SNMP, Relay, EPO.
Data line protection: Telephone, Network.

SKU: OL6KRTMBTF Category: Brand: Cyber Power

Description

CyberPower OL6KRTMBTF Smart App Online UPS Systems

The CyberPower Smart App Online OL6KRTMBTF is a 8U rack/tower UPS featuring double-conversion topology for seamless power protection, an intuitive maintenance bypass switch design, a pre-installed RMCARD205 and a 2U step-down transformer to support 120 V and 200-240 V output requirements. Ensure maximum efficiency and capacity output with a Power Factor rating (PF) of 1. The energy-saving GreenPower UPS™ ECO Mode enables up to 96% efficiency while reducing power consumption and thermal dissipation. Smart battery management charging technology increases battery life up to 50% and replenishes battery charge from 0-90% in four hours.

The OL6KRTMBTF enhanced LCD control panel functionality provides the ability to change the IP address, view UPS load energy consumptions, and select UPS diagnostic tests.

Variable 4-speed fans provide automatic thermal management, based on power load, to reduce noise. A tamper-proof input circuit breaker ensures power is not turned off unexpectedly during service or maintenance. The OL6KRTMBTF simplifies installation with a quick start guide, user-friendly lifting straps, and an enhanced hanging rack mount rail system.

The optional BP240VL3U01 Extended Battery Module expands runtime and speeds restoration of full backup power. The OL6KRTMBTF comes with a three-year warranty (including batteries) and a $300,000 Connected Equipment Guarantee.

Additional information

Weight 485.38 lbs
Dimensions 32.30 × 17.05 × 13.90 in
Application/Usage Server Room, Storage System, VoIP, Hyperconverged Infrastructure (HCI), Lab Equipment, High-end System Component, Electronic Device, Server, Network Device, Network Equipment
Battery Chemistry Lead Acid
Package Contents Smart App Online 6KVA Rack/Tower UPS, USB Cable, Serial Cable , Phone Cable, Rack Mounting Hardware,
Product Type Dual Conversion Online UPS
Input Voltage 120 V AC, 230 V AC
Manufacturer Part Number OL6KRTMBTF
Manufacturer Website Address http://www.cyberpowersystems.com
Limited Warranty 3 Year
Output Voltage 120 V AC, 200 V AC, 208 V AC, 220 V AC, 230 V AC, 240 V AC
Form Factor Rack/Tower
Load Capacity 6000 VA
Manufacturer CyberPower Systems, Inc
Product Name Smart App Online 6KVA Rack/Tower UPS
Network Management SNMP Manageable
Waveform Type Sine Wave
Product Series Smart App Online UPS
Rack Height 8U
Brand Name CyberPower
Plug/Connector Type Hardwired
Input Voltage Range 120 V AC - 139 V AC, 200 V AC - 240 V AC
Country of Origin China
Receptacle Type NEMA 5-20R, NEMA L6-20R, NEMA L6-30R, Hardwired
Environmentally Friendly Yes
Environmental Certification GreenPower UPS, RoHS
Product Condition New
Backup/Run Time (Half Load) 13 Minute
Backup/Run Time (Full Load) 4.40 Minute
Replaceable Battery Yes
Typical Battery Recharge Time 4 Hour
Product Color Black
Receptacle Detail 6 x NEMA 5-20R, 2 x NEMA L6-20R, 4 x NEMA L6-30R, 1 x Hardwired
Additional Information Replacement Battery Cartridge Quantity: 2, Smart Battery Management (SBM) Mode: Yes, Rail Depth - Max. Mounting: 36.02 in (914.91 mm), Rail Depth - Min. Mounting: 20.47 in (519.94 mm), Step-Down Tranformer - Rack Units: 2U, Step-Down Tranformer - Weight (lb): 95.48, Step-Down Transformer Dimensions - WxHxD (in): 17.05 x 3.46 x 23.6 in, Maintenance Bypass Module - Dimensions (WxHxD, in): 7.8 x 10.4 x 6.3, Maintenance Bypass Module - Rack Units: 6U, Maintenance Bypass Module - Weight (lb): 13, Battery Module Dimensions - WxHxD (in): 17.05 x 5.2 x 26 in, Battery Module - Rack Units: 3U, Battery Module - Weight (lb): 167.2, Power Module Dimensions - Wu00d7Hu00d7D (in): 17.05 x 5.2 x 26.0 in, Power Module - Rack Units: 3U, Power Module - Weight (lb): 52.8, Backfeed Protection: Yes, Cold Start: Yes, Input Power Factor: 0.99, Bypass: Internal Bypass (Automatic and Manual), Crest Factor: 3:1, ECO Mode Voltage Regulation: ±10%, ±15% (configurable), Harmonic Distortion: < 3% at Linear Load, Nominal Output Voltage: 118 - 122 VAC, Outlet Type COMPUTED: 6 - NEMA 5-20R, Output Frequency: 49.75 - 50.25 Hz (auto-sensing/configurable), Output Power Factor: 1, Short Circuit Protection: UPS Output Cut off Immediately, Step Down Thermal Dissipation: 1379 BTU/hr, Dry Contacts: Yes, LCD: Multifunction LCD, Management Cable: USB Cable, Removable LCD Control Panel Option: Yes - Requires DB26 cable (not included), Rotatable LCD Control Panel Option: Yes, Serial Port: 1 Serial, Software (Free Download): PowerPanel® Business, Material of Construction: Metal, Mounting Hardware: Yes, Audible noise at 1m from surface of unit: 38 dBA to 65 dBA (0% to 100% load), ECO Mode Thermal Dissipation: 809 BTU/hr, Operating Relative Humidity: 0 - 90 % (non-condensing), Operating Temperature: 32 - 104 °F (0 - 40 °C), Storage Relative Humidity: 0 - 95% (non-condensing),
Software Included PowerPanel® Business Edition
Sound Emission 65 dB(A)
Certifications & Standards UL1778 5th Ed.
Dataline Protection RJ-11, RJ-45
Status Indicators Power On (White), Line Mode (Green), Battery Mode (Yellow), Bypass Mode (Yellow), Fault (Red), Replace Battery (Red),
Overload Protection Yes
Surge Energy Rating 2430 J
Thermal Dissipation 622.78 W
Output Frequency 60 Hz
Alarm Battery Mode, Low Battery, Overload, UPS Fault
Input Frequency 70 Hz
Battery Size 12V
Battery Capacity 7000 mAh
Maximum Operating Temperature 104°F (40°C)
Serial Port Yes
Number of Batteries 20
Battery Characteristics Sealed
EMI/RFI Noise Filter Yes
Directly Connected Equipment Guarantee $300000Lifetime
DC System Voltage 12 V DC
Energy Saving ECO Mode Efficiency >96%
EPO Port Yes
USB (HID Compliant) Port Yes
Maximum Operating Elevation 10000 ft
Maximum Storage Elevation 50000 ft
Operating Humidity 0% - 90%
Storage Relative Humidity 0% - 95%
Storage Temperature -4°F (-20°C) - 113°F (45°C)
Transfer Time 0 ns
GTIN 0649532620340
UPC 649532620340
EAN 0649532620340
UNSPSC 39121011
