Meraki MS425-32 Cloud Managed 10GbE Switch with Enterprise License

Meraki MS425-32 Cloud Managed 10GbE Switch with Enterprise License



SKU: MS425-32~PVAR Categories: , Brand: Cisco Meraki

Description

The Meraki MS425-32 Cloud Managed 10GbE Switch brings powerful cloud-managed switching to the aggregation layer. This 10Gbps fiber aggregation switch adopts the benefits of the cloud: simplified management, network wide control, and lower cost.

The Meraki MS425 series is available in 2 different port densities, 16 or 32 x 10G SFP+. Both include 2 × 40G QSFP+ uplink/stacking ports capable of up to 160Gbps stacking bandwidth.

Super-easy setup

We’ll talk about setup first. Meraki MS switches are wonderful at allowing a network admin to configure a VPN mesh network without having to have highly specialized knowledge. Unlike Cisco switches, there is no CLI, there is only a GUI. Also, Meraki support helps you set it up as you add nodes to your network. Meraki MS switches are amazingly easy to deploy, and amazingly easy to manage. Period.

As a matter of fact, this is true everything Meraki makes. They do it better than pretty much anybody else.

Zero-touch provisioning means that Meraki is brilliant for companies with limited IT teams or IT agencies looking to reduce site calls.

The Meraki MS425 series is a high performance L3 branch and campus line. It’s capable of higher capacity routing and stacking bandwidth than the lower down models. Just email us, or call Corporate Armor at 866-861-2498 and let help show you what 5-star Corporate Armor service is all about!



Meraki MS425 Cloud Managed 10GbE Switch

  • Managed via the Cisco Meraki Dashboard
  • Automatic Firmware upgrades
  • 16 or 32 x 10,000 Mbps SFP+
  • L3 Switching including OSPF
  • Switching capacity up to 800Gbps
  • Stacking bandwidth up to 160Gbps



Datasheet





Additional information

Weight 24.55 lbs
Dimensions 632.00 × 584.00 × 152.00 in
License

No License, Enterprise

Duration

Hardware Only, 1 Year, 3 Years, 5 Years, 7 Years, 10 Years

Product Description Cisco Meraki Cloud Managed Ethernet Aggregation Switch MS425-32 - switch - 32 ports - managed - rack-mountable
Device Type Switch - 32 ports - managed - stackable
Enclosure Type Front to back airflow rack-mountable 1U
Subtype 10 Gigabit Ethernet
Ports 24 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ (uplink)
Performance Switching capacity: 800 Gbps
Capacity Tagged VLANs: 4095
Routing Protocol OSPFv2, static IP routing
Features Layer 3 switching, DHCP support, VLAN support, IGMP snooping, port mirroring, E-mail alert, Broadcast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Quality of Service (QoS), SMS alert, LLDP support, Link Aggregation Control Protocol (LACP), Zero Touch Auto Provisioning, tagged VLAN, cloud managed
Compliant Standards CSA, C-Tick, IC, RoHS
Power AC 120/230 V (47 - 63 Hz)
Manufacturer Warranty Limited lifetime warranty
Authentication Method RADIUS
Interfaces 24 x 1000Base-X SFP+ u00a6 2 x 40Gbit LAN QSFP+ uplink/stacking u00a6 1 x management (Gigabit LAN) RJ-45
Power Device Internal power supply
Voltage Required AC 120/230 V (47 - 63 Hz)
MTBF 431,380 hours
Service & Support Limited warranty - advance hardware replacement - lifetime - response time: next day
Min Operating Temperature 32 u00b0F
Max Operating Temperature 104 u00b0F
